U5 12v~24v 7kg Thrust Brushless Underwater Thruster/Propeller/Propulsion With Bi-Directional Control Esc For Rov And Boat
APISQUEEN U5 Thruster + 100A Non-Waterproof ESC User Manual (Operation method is the same for waterproof ESC):
Propeller Replacement Method：
We are the source factory, for bulk purchase / customization please contact us at lynn@underwaterthruster.com.
Motor:3550;
KV:350;
Maximum thrust: 6±1Kg(One Thruster thrust)；
Power:800W;
Voltage:12-24V（When the battery is fully charged, the ESC supports up to 29.2V）;
Material:Nylon shell;
Individual thruster weight:1.15kg；
Length of one thruster line:1.5 m；
Plug:4.0mm；
ESC:100A/XT60/4.0；
U5 Applicable environment: freshwater.
Use in fresh water, use in seawater is not supported.
DESCRIPTION OF THE UNDERWATER THRUSTERS CW AND CCW
At the same time, we have developed the assistant software. If you need to set the ESC, you can use our assistant software. At the same time, you need to buy the assistant USB .
Software download link (click on the link to download): https://cdn.shopifycdn.net/s/files/1/0621/5493/2452/files/ApisQueen_tool.zip?v=1677690776
【If you can't find the com port, you need to download and install Ch340 or Ch341 driver. Connect the computer and ESC signal cable with Usb, click Tools, select com port, click Connect, then power on the ESC, confirm the connection is successful, then Readpara to read the parameters, then modify the corresponding parameters, then click writepara to write and save.】
About points (lower right corner of the store page):
★5 points for every $1 spent;
★For every 100 points redeemed, you can get a $1.00 discount on the entire order;
Applicable to orders of any amount.How to use points:
1. Redeem in the smile panel.
2. Redeem at checkout.
Customer Reviews
Ordered, Shipped, arrived in a timely manner. Asked a couple of questions via Web chat and got good answers, you have to program the ESC to get it to function correctly in my case from Bi-directional to uni-directional, but that was surprisingly easy! Thanks to ApisQueen so far, the real test will be when I get it in the water.
All good, Web site is a little confusing.
Thought I was ordering the ESC and controller as well as the Thruster, but to do this you have to scroll down to select. The complete kit should be automatically selected and change if required.
This unit is great except for the plastic propeller. One of mine broke less than a month in and the website doesn't offer a replacement that I could find. I had to purchase a whole new motor replacement.
Hello, we are sorry for the bad experience. We have now added the U5 propeller: https://www.underwaterthruster.com/products/apisqueen-80mm-pc-plastic-propeller
Great product. Just arrived those ordered 15 days ago.
The motors are perfect for my application, I am already using some bought 1 year ago.
